Brass PPR Insert (Female Threaded)
A female-threaded brass insert designed specifically for integration into PPR pipe fittings during the injection molding process. Manufactured from IS 319 grade brass with precision threading in ISO Metric and BSP standards. The knurled retention bands ensure a permanent mechanical bond with the surrounding polypropylene material. Available in sizes from ½" (DN15) to 2" (DN50). Applications include faucet and water heater connections, washing machine inlets, radiator valves, and underfloor heating manifolds.
Key Highlights
Features & Benefits
Corrosion Resistant
Manufactured from high-grade CDA C36000/C38500 brass alloys that provide exceptional resistance to dezincification, corrosion, and chemical attack in both hot and cold water environments.
Temperature Resistant
Engineered to withstand continuous operating temperatures from -10°C to +95°C without degradation of mechanical properties or seal integrity.
Precision Threading
All threads are CNC-machined to ISO 228 / BSP / NPT standards with Go and No-Go gauge verification. Thread tolerances of ±0.05mm ensure reliable, leak-free connections.
Easy Installation
Designed for straightforward integration into PPR, CPVC, and UPVC pipe fittings during injection moulding, heat fusion, or mechanical coupling processes.
Technical Specifications
| Specification | Details |
|---|---|
| Product Code | CI-PPR-002 |
| Material | CDA C36000 / C38500 Free-Cutting Brass |
| Thread Standards | ISO 228, BSP, NPT, ISO Metric |
| Size Range | ½" (DN15) to 4" (DN100) |
| Pressure Rating | Up to PN25 (25 bar) at 20°C |
| Temperature Range | -10°C to +95°C continuous |
| Surface Finish | Natural brass, Nickel plated, Chrome plated |
| Knurl Pattern | Diamond, Straight, Cross-hatch |
| Compliance | ISO 228, DIN 8077/8078, ASTM D2846 |
Material & Quality Assurance
Our PPR/CPVC/UPVC brass inserts are manufactured from premium free-machining brass alloys, primarily CDA C36000 and CDA C38500. These alloys offer an optimal balance of machinability, corrosion resistance, and mechanical strength. Lead-free brass variants (CDA C69300) are available for NSF/ANSI 61 compliance.
Usage & Installation Guide
These inserts are designed for permanent installation into thermoplastic pipe fittings. During the injection moulding process, the brass insert is placed into the mould cavity, and the molten plastic flows around it, creating a permanent mechanical and thermal bond. The knurled outer surface provides exceptional pull-out resistance.
Applications & Industries
The Brass PPR Insert (Female Threaded) is widely used across diverse industrial sectors:
Why Choose Chetna Industries for Brass PPR Insert (Female Threaded)?
Chetna Industries is a trusted manufacturer and global supplier of precision brass components with expertise in CNC machining and brass insert manufacturing.
- State-of-the-Art Manufacturing: Swiss-type CNC lathes and multi-axis machining centers capable of producing millions of precision brass components monthly.
- Custom Engineering Support: In-house DFM analysis, material selection guidance, and custom product development.
- Global Quality Standards: ISO 9001:2015 certified with full traceability and compliance with DIN, ISO, ASTM, and ASME specifications.
- Competitive Pricing: Direct manufacturer pricing with flexible MOQ. Transparent quotes within 24 hours.
- Reliable Global Supply: On-time delivery worldwide. Standard products ship within 7-10 business days.
Related Products
.webp)
Ready to Order Brass PPR Insert (Female Threaded)?
Contact our sales team for pricing, custom specifications, or technical support. We respond within 24 hours.
